Fully Automatic Strip Back Sealing Packaging Machine
The Fully Automatic Strip Back Sealing Packaging Machine represents a pinnacle of modern packaging engineering, designed to deliver unparalleled efficiency and reliability in continuous production environments. This advanced system specializes in strip-style back sealing, utilizing a precise diagonal straight horizontal sealing mechanism to create robust, consistent packages. Engineered to handle both paper and plastic packaging materials, it offers exceptional versatility for a broad spectrum of product forms, including powders, granules, and liquids. At its core, the integration of a high-precision Siemens servo bag-pulling system and an intuitive touch-screen human-machine interface (HMI) ensures operational excellence, providing users with precise control, smooth workflow integration, and dependable performance for demanding packaging lines.
Product Features
High-Speed, Stable Production: Engineered for efficiency, the machine achieves a consistent output of 20 to 50 bags per minute, reliably meeting high-volume daily production targets. Its robust mechanical design ensures unwavering performance in bag forming, sealing, and cutting cycles, minimizing downtime and maximizing throughput.
Robust and Clean Back Sealing: The innovative diagonal straight seal structure is a cornerstone of this machine’s design. It generates a tight, uniform, and durable seal that significantly enhances package integrity. This feature is critical for maintaining product freshness and preventing leaks during extended storage and rigorous transportation.
Exceptional Packaging Adaptability: Designed for flexibility, the machine seamlessly accommodates both paper and plastic films. It supports a wide bag size range from Length 50–200 mm and Width 25–150 mm, enabling quick and easy changeovers between different product SKUs and packaging formats, thus optimizing production line versatility.
Precise and Adjustable Temperature Control: Equipped with a highly accurate temperature regulation system adjustable from 0 to 300°C, the machine guarantees stable and optimal sealing performance across diverse film types and thicknesses. This precise control is instrumental in virtually eliminating common sealing defects such as weak seals or film burn-through.
Servo-Driven Precision with Siemens Technology: The incorporation of a Siemens servo motor for the heat-sealing bag pulling mechanism sets a new standard for accuracy. This system delivers exceptional bag length precision, consistent feeding stability, and superior repeatability, which is particularly advantageous during prolonged, uninterrupted production runs.
Durable and Hygienic Construction: Built with longevity and cleanliness in mind, the machine’s primary structure utilizes high-grade 304 stainless steel. This material offers excellent corrosion resistance and facilitates effortless cleaning and maintenance, making the machine perfectly suited for stringent hygienic production environments like food and pharmaceuticals.
Intuitive and User-Friendly Operation: A centralized touch-screen HMI simplifies all aspects of machine operation. From parameter setting and real-time production monitoring to facilitating quick changeovers, the interface significantly reduces operator workload, minimizes the potential for human error, and shortens required training periods.
Versatile Cutting Options: To cater to diverse end-user preferences and product presentation needs, the machine offers a choice between a clean flat cut and a user-friendly serrated cut. This flexibility allows manufacturers to tailor the package opening experience to their specific market requirements.
Technical Specifications
| Parameter | Detail |
|---|---|
| Product Name | Fully Automatic Strip Back Sealing Packaging Machine |
| Machine Type | Automatic Strip Packaging Machine |
| Horizontal Sealing Form | Diagonal Straight Seal |
| Available Cutting Methods | Flat Cut / Serrated Cut |
| Packaging Speed | 20–50 bags per minute |
| Bag Size Range (L × W) | Length: 50–200 mm, Width: 25–150 mm |
| Sealing Temperature Range | 0–300°C (adjustable) |
| Control & Display Interface | Touch Screen HMI |
| Operating Voltage | 220V |
| Power Consumption | 2.2 kW |
| Bag Pulling Mechanism | Servo Motor Heat Sealing Bag Pulling (Siemens) |
| Primary Construction Material | 304 Stainless Steel |
| Machine Dimensions (L × W × H) | 1500 mm × 1000 mm × 2200 mm |
| Approximate Machine Weight | 500 kg |
| Compatible Packaging Materials | Paper / Plastic Films |
Application Fields
This fully automatic strip back sealing packaging system is the ideal solution for manufacturers across numerous industries who require efficient, single-lane strip packaging with guaranteed seal reliability and clean, professional cutting. Its robust design and precise control make it widely applicable in the following sectors:
Food and Beverage Industry: Excellently suited for packaging seasonings, granulated sugar, instant coffee, tea granules, powdered drink mixes, and small liquid condiment sachets, where maintaining product freshness through stable sealing and achieving neat bag presentation are paramount.
Pharmaceutical and Healthcare Sector: Ideal for packaging powdered supplements, medicinal granules, and other healthcare products that demand stringent hygiene standards, consistent bag length control, and repeatable, precise sealing temperature management for product safety and integrity.
Daily Chemical Products: Perfectly designed for packaging detergents, cleaning powders, bath beads, and small-dose liquid chemicals, where reliable back sealing, controlled output speeds, and robust construction to handle various compositions are essential.
Industrial and Agricultural Products: Highly effective for packaging fine industrial powders, plastic pellets, agricultural seeds, fertilizers, and small granules, where the machine’s durable structure and capability for continuous, high-volume operation provide critical production advantages.
