Pack Mate DS320A High-Speed Poly Bag Packing Machine
The Pack Mate DS320A represents a pinnacle of efficiency in automated packaging, engineered as a fully integrated system for the continuous forming, filling, and sealing of poly bags. This robust machine is purpose-built to deliver unwavering performance in high-demand production settings, seamlessly handling a diverse spectrum of products including powders, granules, and various liquids. At its core, the DS320A is designed to maximize output while guaranteeing pouch integrity, making it the definitive solution for operations requiring high-volume packaging of sachets and small pouches within the 50–500 ml capacity range. Its advanced servo-driven mechanisms ensure precision in every cycle, establishing a new standard for speed, reliability, and sealing quality in modern packaging lines.
Core Product Features
Unmatched Production Velocity and Stability
Engineered for peak throughput, the DS320A achieves an impressive operational speed of 30 to 50 bags per column per minute. This high-speed capability is consistently maintained across varying material types and fill volumes, ensuring production lines meet aggressive targets without compromising on the stability of the packaging process or the quality of the final pouch.
Precision Servo-Driven Film Handling
Accuracy begins with control. The machine employs a sophisticated servo motor drive system that governs both the hot sealing function and the precise pulling of the packaging film. This integration is critical for achieving exceptional consistency in bag length and superior feeding accuracy. For operations demanding even greater smoothness at elevated speeds, an optional configuration featuring roller bag pulling driven by a premium Schneider servo motor is available, further enhancing operational fluidity and control.
Engineered Sealing for Maximum Integrity
Product protection is paramount. The DS320A’s sealing structure is meticulously designed to create dependable, leak-resistant pouches using composite packaging films. It utilizes straight-line sealing with precisely controlled spacing and a generous 10 mm sealing width, which collectively enhance both the barrier properties and the aesthetic appeal of the package. For liquid packaging applications, an integrated 1 mm horizontal sealing leak-proof line provides an additional layer of security, ensuring pouch integrity even under stress.
Adaptable Design for Diverse Product Lines
Versatility is built-in. Supporting a practical and wide bag-making range, the DS320A allows for rapid adaptation to different product specifications and packaging formats. This inherent flexibility is ideal for manufacturing facilities that manage multiple Stock Keeping Units (SKUs) or require frequent changes for seasonal products, significantly reducing changeover time and boosting overall line agility.
Efficient and Durable Industrial Construction
Designed for longevity and cost-effectiveness. The machine boasts remarkably low gas consumption of just 0.2 m³/min, contributing to reduced operational expenses. Housed within a solid, 350 kg machine body, the DS320A is built to withstand the rigors of continuous, long-term use, offering outstanding mechanical stability that translates into consistent performance and minimal downtime.
Technical Specifications
| Parameter | Detail |
|---|---|
| Product Designation | High-Speed Poly Bag Packing Machine (Automatic Pouch Filling & Sealing) |
| Model | DS320A |
| Machine Weight | 350 kg |
| Operational Speed | 30–50 bags/column/minute |
| Packaging Capacity Range | 50–500 ml |
| Compatible Product Forms | Powders, Granules/Particles, Liquids |
| Packaging Film Type | Composite Packaging Material |
| Bag Dimension Capacity (Width × Length) | 50 mm ≤ Width ≤ 150 mm; 30 mm ≤ Length ≤ 240 mm |
| Primary Film Advancement System | Servo Motor Drive (integrated hot sealing & film pulling) |
| Optional Film Advancement | Roller Bag Pulling (Powered by Schneider Servo Motor) |
| Filling Accuracy | ±1% to ±10% (varies based on material properties and fill quantity) |
| Compressed Gas Consumption | 0.2 m³/min |
| Forming Machine Width | ≤ 320 mm (includes one flip-collar forming unit) |
| Vertical Sealing Configuration | Folded edge on back, straight lines on sides (2 mm spacing) |
| Horizontal Sealing Pattern | Straight pattern (2 mm spacing), Sealing Width: 10 mm |
| Horizontal Leak-Proof Sealing Line | 1 mm width (specifically for liquid packaging) |
| Pouch Separation Method | Pattern Cutting (3 mm spacing) |
| Registration Mark Sensor | JULONG Brand Optoelectronic Eye |
Primary Application Industries
Food & Beverage Sector
Ideal for the efficient packaging of liquid condiments, beverage syrups, powdered seasonings, and other small-volume food ingredients. The machine’s consistent sealing and pouch formation are critical for maintaining product freshness, preventing leaks, and ensuring attractive retail presentation.
Pharmaceutical & Healthcare Products
Well-suited for packaging medicinal powders, granular supplements, and single-dose formulations into sachets. The precise bag dimension control and repeatable film handling are essential for meeting stringent industry standards for dosage consistency and package integrity.
Industrial & Household Chemicals
Capably handles the packaging of fine chemical powders, granular compounds, and liquid agents used in detergents, additives, and various industrial applications. Its compatibility with robust composite films ensures safe containment of these products.
Cosmetics & Personal Care
Perfect for creating sample-sized and travel-friendly pouches for lotions, serums, and powdered cosmetics. The optional leak-proof sealing line provides essential security for liquid-based products, enhancing brand trust and customer satisfaction.
